4-20ma Profibus Converter Conversion Device Converter

NCS-FI105 fieldbus to current Converter is used to convert fieldbus signals to conventional analog signals. It can receive fieldbus signals, and convert them to 4-channel 4~20mA analog signals. NCS-FI105 is the converter between fieldbus system and control valve/other actuator. NCS-FI105 is an intelligent instrument and complies with FF Fieldbus Specification. It can be interlinked with several FF equipment.

Features

Number of channels:4

Output of signal:4-20mA

Bus signal:31.25kbit/s

Power:9-32VDC

Current consumption(static):≤ 14mA
