Wyłącznik Euchner SN01R553-M
- Producent:
- Euchner
- Numer katalogowy:
- 085253
Wyłącznik krańcowy Euchner 085253
Housing material
Housing Anodized die-cast alloy
Weight
Net 0,1 kg
Ambient temperature -5 ... 80 °C
Degree of protection IP67
Mechanical life 10 x 106
Contact material Silver alloy, gold flashed
Switching principle Changeover contact with snap-action function
Installation orientation Any
Tightening torque
Screw terminal switching element max.0,2 Nm Hexagon socket AF 1.3 mm
Number of door position NC contacts 1 Changeover contact
Number of door position NO contacts 1
Connection
1 x M16 x 1.5
Approach speed 0,01 ... 50 m/min
Actuating element
Plain bearing metal Roller plunger
Actuating force 15 ... 20 N
Electrical connection ratings
Thermal rated current Ith 6 A
Utilization category acc. to EN 60947-5-1
AC-15 2A 230V
DC-13 2A 24V
Short circuit protection according to IEC 60269-1 6A gG
Rated insulation voltage Ui 250 V
Rated impulse withstand voltage Uimp 2,5 kV
Switching current
Min. at DC 24V 10 mA
Wyłącznik Euchner SN01R553-M - karta katalogowa :
https://www.euchner.de/en-us/products/position-switches-multiple-limit-switches/precision-single-limit-switches-n01-nb01-and-sn01/sn01r553-m/
